Product Overview
Zeolite Ceramic Ball, also known as Molecular Sieve Zeolite Ceramic Ball, is an advanced adsorption filtration media designed for water purification, wastewater treatment, and environmental purification applications. The product is mainly composed of natural clinoptilolite (zeolite), kaolin, and pore-forming agents, processed through a controlled low-temperature firing process at approximately 650°C using rapid sintering technology.
This manufacturing method helps retain the natural adsorption and ion exchange properties of zeolite while forming a stable porous ceramic structure with uniformly distributed micropores. The product exhibits strong adsorption capacity, excellent purification performance, and catalytic activity, making it highly effective for removing hardness ions, fluoride, heavy metals, ammonia nitrogen, organic pollutants, and certain specialised contaminants in water treatment systems.
Key Functions
- Helps soften hard water by reducing calcium (Ca²⁺) and magnesium (Mg²⁺) hardness ions
- Supports reduction of fluoride content in treated water
- Adsorbs heavy metal ions such as lead (Pb), cadmium (Cd), copper (Cu), zinc (Zn), and nickel (Ni)
- Supports removal of ammonia nitrogen (NH₃-N) in wastewater treatment applications
- Adsorbs selected organic pollutants and odour-causing compounds
- Suitable for household water purification, wastewater treatment, and environmental purification systems
Product Advantages
- Natural zeolite-based molecular sieve ceramic formula
- Strong adsorption and ion exchange capability
- Uniform microporous structure for efficient water-media contact
- Excellent purification and catalytic performance
- Stable ceramic body with long service life
- Suitable for OEM filtration cartridges and customised purification systems
Technical Parameters
| Parameter |
Specification |
| Product Name |
Zeolite Ceramic Ball / Molecular Sieve Zeolite Ceramic Ball |
| Main Material |
Clinoptilolite (Natural Zeolite), Kaolin, Pore-Forming Agents |
| Processing Temperature |
Approx. 650°C (Low-Temperature Fast Firing) |
| Structure |
Uniform Microporous Molecular Sieve Structure |
| Main Function |
Adsorption / Ion Exchange / Water Purification |
| Application |
Water Purification / Wastewater Treatment / Environmental Purification |
How It Works
Ion Exchange
Natural zeolite minerals provide ion exchange capability, helping reduce hardness ions such as calcium and magnesium while capturing ammonia nitrogen and selected contaminants in water.
Molecular Sieve Adsorption
The uniformly distributed microporous structure exhibits molecular sieve characteristics, allowing strong adsorption of polar molecules, unsaturated compounds, and easily polarisable substances.
Heavy Metal and Pollutant Removal
The porous zeolite ceramic structure helps adsorb heavy metals, fluoride, selected organic pollutants, and odour-causing substances, improving water clarity and overall water quality.
Product Test
| Time (Minutes) |
Flow Rate (L/min) |
Ammonia Nitrogen (mg/L) |
| 0 |
1.2 |
0.14 |
| 5 |
1.0 |
0.12 |
| 10 |
1.2 |
0.09 |
| 20 |
1.0 |
0.05 |
| 30 |
1.2 |
0.02 |
| 60 |
1.2 |
<0.01 |
| 120 |
1.2 |
<0.01 |
Product Applications
- Household water filtration systems
- Water bottles and drinking cups
- Shower filters
- Electric kettles and water dispensers
- Filter cartridges and purifier systems
- Plant cultivation and aquarium filtration
- Air purification and humidifier purification systems
- Environmental purification and specialised treatment equipment
Frequently Asked Questions
What are Zeolite Ceramic Balls used for?
They are used in water purification and environmental treatment systems to help remove ammonia nitrogen, hardness ions, heavy metals, fluoride, and selected organic contaminants.
How do Zeolite Ceramic Balls work?
They use the natural ion exchange and adsorption properties of zeolite combined with a porous ceramic molecular sieve structure to capture contaminants and improve water quality.
Can Zeolite Ceramic Balls be used in household water filters?
Yes. They are commonly used in drinking water cups, shower filters, filter cartridges, kettles, and other household purification products.
Can they be combined with other filtration media?
Yes. Zeolite Ceramic Balls are often used together with activated carbon, Maifan Stone Ceramic Balls, antibacterial ceramic media, and other functional filtration materials in multi-stage systems.
