Product Overview
Silicon Hydrogen Ceramic Ball is a high-performance functional water treatment media designed for rapid hydrogen generation, ORP reduction, weak alkaline water production, and water quality enhancement. The product is manufactured using silicon-based mineral materials combined with functional ceramic technology through controlled sintering processes, forming a stable ceramic structure capable of rapid reaction with water.
When placed into purified water or tap water, the ceramic balls react quickly and continuously release hydrogen bubbles that dissolve into water, helping create hydrogen-rich water. During the reaction process, the ceramic media also supports micro-electrolysis reactions that reduce oxidation-reduction potential (ORP), release beneficial mineral ions, and adjust water into a weakly alkaline condition.
Compared with conventional hydrogen ceramic media, Silicon Hydrogen Ceramic Balls provide faster reaction speed, stronger hydrogen generation capability, and higher ORP reduction performance, making them suitable for hydrogen water bottles, filtration systems, household water treatment equipment, and OEM functional water applications.
Key Functions
- Rapid hydrogen generation in water
- Supports reduction of oxidation-reduction potential (ORP)
- Helps adjust water into a weakly alkaline condition
- Improves water quality, freshness, and taste
- Supports release of beneficial mineral elements
- Suitable for multi-stage filtration and hydrogen-rich water systems
Product Advantages
- Fast reaction speed after contact with water
- High hydrogen production performance
- Stable alkaline pH support
- Cost-effective solution for functional filtration systems
- Durable ceramic structure with stable performance
- OEM particle size, formulation, and packaging available
- Compatible with household and commercial water systems
Technical Parameters
| Parameter |
Specification |
| Product Name |
Silicon Hydrogen Ceramic Ball |
| Main Material |
Silicon Mineral Functional Ceramic Materials |
| Function |
Hydrogen Generation / ORP Reduction / Weak Alkaline Support |
| Reaction Characteristic |
Rapid Reaction After Water Contact |
| OEM Support |
Custom Size and Packaging Available |
Hydrogen Generation Test Data
Test Condition: 30g ceramic balls in 500ml / 750ml water
| Time |
H₂ (ppb) |
pH |
ORP (mV) |
TDS (mg/L) |
| 3 Minutes |
500 / 400 |
9.56 / 9.0 |
-120 / -80 |
18 / 20 |
| 10 Minutes |
1000 / 860 |
9.82 / 9.1 |
-250 / -200 |
46 / 58 |
| 30 Minutes |
1200 / 1080 |
9.99 / 9.5 |
-300 / -240 |
100 / 89 |
| 60 Minutes |
1450 / 1200 |
10.12 / 9.8 |
-350 / -300 |
180 / 150 |
| 1020 Minutes |
1220 / 980 |
9.2 / 9.0 |
-450 / -380 |
330 / 200 |
Trace Element Dissolution Test
Test Condition: 50g ceramic balls in 500ml water
| Element |
Result |
| Mg |
6.71mg |
| Ca |
4.2mg |
| Fe |
0.006mg |
| Na |
0.42mg |
| K |
0.51mg |
| Si |
0.13mg |
| Zn |
1.3mg |
| Pb |
<0.0001mg |
| Cr |
<0.0001mg |
| Sr |
<0.0001mg |
How It Works
Hydrogen Generation
The ceramic balls react rapidly after contact with water, supporting continuous hydrogen bubble release and hydrogen-rich water formation through natural micro-electrolysis reactions.
ORP Reduction
The internal mineral materials help reduce oxidation-reduction potential (ORP), supporting negative potential water conditions suitable for functional water applications.
Weak Alkaline Water Support
Hydroxyl ions generated during the reaction process help adjust water toward a weakly alkaline condition while supporting mineral balance and improved water quality.
Pesticide Removal Performance Test
Testing showed that Silicon Hydrogen Ceramic Balls supported reduction of pesticide residue indicators and bacterial presence in fruit and vegetable washing applications under the described test conditions.
| Sample |
Inhibition Ratio (%) |
E. coli |
| Tap Water – Cucumber |
85 |
72 |
| With Ceramic Ball – Cucumber |
26 |
0 |
| Broccoli |
19 |
0 |
| Green Leaf |
13 |
0 |
| Apple |
15 |
0 |
| Strawberry |
22 |
0 |
Antibacterial Test Data
| Item |
MRSA |
E. coli |
| Pesticide Remove Ceramic Ball |
98% |
99% |
Product Applications
- Hydrogen-rich water systems
- Water filter cartridges
- Hydrogen water bottles and kettles
- Household water purification systems
- Fruit and vegetable washing applications
- Functional water treatment equipment
- OEM filtration systems
Frequently Asked Questions
What is Silicon Hydrogen Ceramic Ball used for?
It is used for hydrogen-rich water generation, ORP reduction, weak alkaline water support, mineral release, and functional water treatment applications.
How does it generate hydrogen?
The internal silicon-based functional materials react with water through micro-electrolysis reactions, supporting hydrogen bubble release and hydrogen-rich water formation.
Can it reduce ORP?
Yes. The ceramic media helps reduce oxidation-reduction potential and supports negative ORP water conditions under suitable operating conditions.
Can it be used with other filter media?
Yes. It is commonly combined with activated carbon, mineral ceramic balls, ORP ceramic media, and antibacterial filtration materials in multi-stage systems.
Can the size and packaging be customised?
Yes. Longxin supports OEM particle size, formulation, and packaging customisation according to customer application requirements.
