Product Overview
Magnesium Hydrogen Ceramic Ball is an advanced functional filtration media designed to generate hydrogen-rich water through non-electrolytic micro-electrolysis reactions. The product is manufactured using a porous ceramic structure combined with magnesium-based hydrogen-generating materials, allowing controlled hydrogen release when the media comes into contact with water.
The ceramic matrix provides structural stability, durability, and safe long-term performance under different water conditions. During operation, the ceramic balls support hydrogen generation, oxidation-reduction potential (ORP) reduction, weak alkaline water adjustment, and overall water quality improvement.
Compared with conventional filtration media, Magnesium Hydrogen Ceramic Balls combine hydrogen generation functionality with durable ceramic structure and multi-stage filtration compatibility, making them suitable for drinking water systems, hydrogen water bottles, shower filtration systems, industrial circulating water systems, and OEM functional water treatment products.
Key Functions
- Supports efficient hydrogen generation in water
- Helps adjust water toward a weakly alkaline condition
- Supports reduction of oxidation-reduction potential (ORP)
- Improves water taste and overall water quality
- Compatible with multi-stage water purification systems
- Suitable for hydrogen-rich functional water applications
Product Advantages
- Stable and continuous hydrogen release capability
- Safe and durable porous ceramic structure
- Compatible with multiple filtration applications and systems
- Long service life with low maintenance requirements
- Environmentally friendly and reusable functional media
- Supports OEM size, shape, and packaging customisation
- Suitable for household, commercial, and industrial water systems
Technical Parameters
| Parameter |
Specification |
| Product Name |
Magnesium Hydrogen Ceramic Ball / Disc |
| Shape |
Spherical / Disc |
| Size |
2–10 mm (Ball) / Customised (Disc) |
| Material |
Porous Ceramic with Magnesium-Based Hydrogen Generating Materials |
| Hydrogen Concentration |
600–1500 ppb |
| pH Range |
8.0–9.5 |
| ORP Reduction |
Supported |
| Service Life |
1–3 Years |
| Temperature Resistance |
≤100°C |
| Application |
Water Purification Systems |
Hydrogen Generation Mechanism
Micro-Electrolysis Reaction
The product generates hydrogen through controlled micro-electrolysis reactions between magnesium-based functional materials and water.
Mg + 2H₂O → Mg(OH)₂ + H₂↑
During this process, dissolved hydrogen is gradually generated and released into the water system.
Hydrogen Dissolution
The microporous ceramic structure enhances hydrogen dissolution and retention, helping form stable hydrogen-rich water suitable for functional water applications.
ORP Reduction and Alkaline Support
The hydrogen generation process helps reduce oxidation-reduction potential (ORP) while supporting weak alkaline water conditions and improving water balance.
Product Applications
- Drinking water purification systems
- Hydrogen water bottles and pitchers
- Shower and bath filtration systems
- Industrial circulating water systems
- Aquaculture and hydroponics systems
- Functional water treatment devices
- OEM hydrogen water products
Product Test
| Parameter |
Typical Result |
| Hydrogen Concentration |
600–1500 ppb |
| pH Value |
8.0–9.5 |
| ORP (mV) |
Negative Range Achievable |
| Test Method |
Immersion Test |
Certifications
- ISO9001 Quality Management System
- ISO14001 Environmental Management System
- SGS Testing Reports
- FDA / LFGB Compliant Materials
Frequently Asked Questions
How does the product generate hydrogen?
Hydrogen is generated through controlled micro-electrolysis reactions between magnesium-based functional materials and water.
Is it safe for drinking water applications?
Yes. The ceramic materials are stable and suitable for drinking water related applications under proper filtration system conditions.
How long does the product last?
Typical service life is 1–3 years depending on water quality, operating conditions, and usage frequency.
Can it be used with other filtration media?
Yes. Magnesium Hydrogen Ceramic Balls are commonly combined with mineral balls, activated carbon, antibacterial ceramic media, and alkaline filtration materials in multi-stage systems.
Can the size and shape be customised?
Yes. Longxin supports OEM customisation for particle size, disc shape, formulation, and packaging according to customer requirements.
